Description
| System | |
| Video compression | H.265+/H.265/H.264HP/H.264MP/H.264BP |
| Audio compression | ADPCM/G.711A/G.711U |
| Operation system | Embedded Linux |
| Signal system | Auto detect |
| Bandwidth throughput | 600Mbps(Incoming 400Mbps) |
| Remote connections | 160Channels |
| Record/Playback/Streaming | |
| IPC input | 80CH @ 4K/6MP/5MP/4MP/3MP/2MP/720P/4CIF |
| Live Screen window | 64CH/40CH/36CH/25CH/20CH/16CH/10CH/9CH/8CH/6CH/4CH/1CH |
| Live resolution | 4CH@4K/6MP, 5CH@5MP, 8CH@4MP/3MP, 16CH@1080P, 32CH@720P, 64CH@4CIF Realtime Display |
| Record resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Record frame rate | Mainstream 25fps(P)/30fps(N), Sub stream 25fps(P)/30fps(N) |
| Record function | Smart Record, Records Encryption, Records TAG, One Key Start Recording, Trigger Recording |
| Smart record | Different recording bitrate at different time zone, i-Frame recording only record key frame to lower frame rate |
| Trigger record | Manual/Timing/Motion Detection/Port Alarm/ IVA Alarm/Video Occlusion |
| Playback channel | 16CH @1080P/720P/D1, 8CH @4MP/3MP, 4CH @4K/6MP/5MP |
| Smart search | YES, Quickly search target iVA videos , Only for iCRYS series cameras |
| Playback function | Play, Pause, Stop, Rewind, Fast, Slow, Next & Previous File/Camera, Full screen, Repeat, Shuffle, Backup selection, Digital Zoom |
| Instant Access Function | Quick playback up to last 5min, Quick backup |
| Record quality | Best/Better/Good/Normal/Worst |
| Record stream Bitrate | VBR/CBR (32 ~ 16384Kb/s) |
| Sub stream | D1/CIF/QCIF, Frame rate selectable |
| Pre & Post alarm record | Pre : 10 ~ 600 sec, Post : 5 ~ 60sec |
| Array & Storage | |
| Array method | RAID0, RAID1, RAID5, RAID10, JBOD(>0℃, Each Raid Group Supports up to 100Mbps Input) |
| Raid management | Single click configuration, Restore automatically and Manually array rebuild |
| Redundant recording | 200Mbps Input |
| Hot backup disk | Raid Hot Backup Disk and Overall |
| Hot Swap | N + M |
| Hot standby | 8 HDD (SATA Port) |
| Hard disk interface | – |
| Hard disk capacity | Max. up to 10TBEach Port |
| E-SATA interface | 1 Port, NAS(NFS for Backup) |
| Management Function | HDD Grouping and Quota, SMART HDD Check, Record file TAG, File lock |
| ANR | Download Stored Video Automatically from Camera SD Card, When NVR Online |
| Intelligent Analytics Functions | |
| Video Analytics | 1~2CH @ Any H.264 Onvif IP Camera(2MP)(Tripwire, Perimeter, Object Detection & Count) and 1Ch ~ 80Ch with iCRYS iVA Process Camera(Facial detection/Fast voving/ Missing & Foreign object/Crowd & Screaming detection /Tripwire/Perimeter/People counting/Loitering/Parking/Blurred image/Audio offline/Off-Position) |
| Video diagnosis | Video color cast detection, Noise Detection, Electromagnetic interference testing, Fuzzy video Detection |
| Motion detection | – |
| Motion detection | – |
| HDD alarm trigger | Disk Full, No Disk, Disk R/W Error, Redundancy Error |
| Intelligent alarm | – |
| Event & Alarm trigger | E-MAIL, Snap, NVR Sound Buzzer, OSD, Alarm Server Devices, Video Recording, Alarm Out, PTZ Trigger |
| Network alarm trigger | illegal Access, IP Address Conflict, Network Lost, MAC Conflict |
| Icrys Series camera Function | Corridor Control, Plug & Play, Image Flip, one key control, |
| Private functions | – |
| Alarm trigger | Local Alarm Port Out, NVR Sound Buzzer, OSD, Alarm Server Devices |
| Video/Audio/Interface | |
| Network | 2 X RJ45 Port – 10/100/1000MBPS Auto Detection(Load Balance, Redundant, Dual IP) |
| HDMI output | 2 X HDMI Port @ Resolution up to 3840×2160,2560×1600, 1920×1080,1280×720, 1280×800,1366×768,800×600,1024×768,1440×900 Adjustable Output, Self-detection |
| VGA output | 2 X VGA Port @ Resolution up to 1920×1080,1280×720,1280×800,1366×768, 800×600,1024×768,1440×900 Adjustable Output, Self-detection |
| Alarm | 16Ch Inputs, 4Ch Outputs, 3P Connector, 0V Signal |
| Audio | – |
| Communication Protocol | 2x RS485, 1x RS232 |
| USB | 3 Port (1 X USB 3.0, 2 X USB2.0) |
| Network protocol | TCP/UDP/MULTICAST/UPNP/HTTP/DHCP/PPPoE/DDNS/NTP/ HTTPS/NFS/FTP/RTSP/SMTP/HTTPS/SADP, Alarm Server, Auto Search iCRYS Series IP Camera |
| Backup | – |
| FTP & E-Mail alert | – |
| Key functions | – |
| Snap shot | <12Kg, 495(D) x 482.6(W) x 132mm(H) |
| Backup | – |
| OSD Setups | Channel Wise Color/Position/Transparency/Text/Masking/Date & Time Format |
| Log generation | Channel, Event based, Date and Time selection, Export |
| Software Supports | |
| Onvif compliant | Yes, Profile S |
| Key function | One key record, One key intercom, Digital zooming |
| P2P cloud | I-Phone, IPAD, Android, Record, Playback, Push Notification, Device controls |
| Web browser | IE, Safari, Chrome, Edge |
| Other functions | E-MAIL Alert, FTP Upload |
| General | |
| Power supply | SMPS 100 ~ 240VAC, 50 ~ 60Hz |
| Power consumption | <80W without HDD |
| Language | English, Spanish, French, German, Chinese & Many More |
| Operation conditions | -10 ℃ ~ +55 ℃ (+14 F~ + 131 F), 10% ~ 90% RH |
| Enclosure | 2U 19″ Rack mount, Black color, Metal case |
| Weight (g) & Dimension | <10Kg, 440(D) x 458(W) x 89mm(H) |
